MEEB2600819
$5,299.00
The Espresso CC range is the rugged sibling of the regular Espresso City, with powerful motors, large capacity batteries and grippier high-volume tyres on 650b wheels. While it's happy working hard in the urban jungle thanks to standard-fit mudguards, lights, lock, rack and kickstand, it's also capable of taking trips along forest trails and gravel tracks for fun.
Rugged enough for the countryside, tough enough for the city. The Espresso CC 500 EQ pairs the new, powerful Shimano EP6 drive unit with a 630Wh battery that sits in Merida’s Energy Cradle frame design. It combines the convenience of an external battery with the looks of an internal battery in order to keep the handling safe and secure. Smooth and comfortable progress is assured with the Suntour 80mm travel suspension fork and reliable Shimano drivetrain, while powerful hydraulic disc brakes allow effortless and controlled stopping. Offering a high system weight of 150 kg which means plenty of capacity for rider and luggage.
Features
Specifications
| FRAME | eSPRESSO CC LITE III; MAT aluminium; 27,5x2,25" max. WHS; 135x9 AST; internal |
| SHOCK | |
| FORK | Suntour NVX30 DS; Coil; 80 STR; 27,5x2,4" max WHS |
| BRAKE FRONT | Shimano MT-200; 2 piston |
| BRAKE REAR | Shimano MT-200; 2 piston |
| ROTOR FRONT | Shimano RT10; 180 mm |
| ROTOR REAR | Shimano RTEM300M; 180 mm |
| CHAIN | Shimano LG500 |
| CHAINGUARD | Sunnywheel SW-CG-173A |
| CHAINRING | Samox NWP203 ; 38t |
| CRANKSET | MERIDA EXPERT TK; 165mm |
| BOTTOM BRACKET | |
| DERAILLEUR FRONT | |
| DERAILLEUR REAR | Shimano CUES U6000; GS |
| CASSETTE | Shimano LG300; 11-48t; 10t |
| PEDAL | VP VPE-891 |
| GRIP | MERIDA EXPERT TK |
| HANDLEBAR | MERIDA EXPERT; MAT aluminium; 660 WHB; 15 RHB |
| STEM | MERIDA EXPERT CT; MAT aluminium; 31.8 DSH; adjustable |
| STEM SIZE | 90 mm- XS/S/M/L/XL |
| HEADSET | MERIDA-8254 |
| HUB FRONT | Shimano QC300; 100x9 WHF; 32 SPH; Centerlock |
| HUB REAR | Shimano QC300; 135x9 WHR; 32 SPH; Centerlock |
| AXLE FRONT | |
| AXLE REAR | |
| RIM | MERIDA COMP TK; 20 IWR; MAT aluminium |
| RIM TAPE | |
| SADDLE | MERIDA EXPERT TK II; V-mount |
| SEAT CLAMP | MERIDA EXPERT |
| SEAT POST | JD-SP79; 30.9 DSP; 15 SSB; 40 SST |
| SHIFTER FRONT | |
| SHIFTER REAR | Shimano CUES U6000-10 |
| TYRE FRONT | Maxxis Crossmark II; 27.5x2.25"; wire; reflecting line |
| TYRE REAR | Maxxis Crossmark II; 27.5x2.25"; wire; reflecting line |
| CARRIER | MERIDA MIK HD Carrier with Spring clip & Spanninga rear light |
| FENDER | Sunnywheel SW-FA-311-65(MSB) |
| KICKSTAND | Atranvelo ED-100-PC |
| LIGHT-FRONT | Herrmans H-Black MR4 E |
| LIGHT-REAR | Spanninga Commuter Glow XE integrated in MERIDA MIK HD carrier |
| FRAME LOCK | Abus 4650 XL |
| DRIVE UNIT | Shimano EP6; 85Nm |
| BATTERY | Shimano EN806; 630Wh |
| DISPLAY | Shimano SC-EN500 |
